VLT AutomationDrive FC 301/302
Programming Guide
Enter the filter time constant. This is a first-order digital low-pass filter time constant for suppressing electrical noise in terminal
X49/5. A high time constant value improves dampening but also increases the time delay through the filter.
5.29.5 36-4* Output X49/7
The following parameter is only available in FC 302:
-
Parameter 36-41 Terminal X49/7 Digital Output
Use the parameters in this group to configure the mode of inputs and outputs of VLT® Programmable I/O MCB 115.
Parameter 36-40 Terminal X49/7 Analogue Output
Table 1330: Parameter 36-40 Terminal X49/7 Analogue Output
36-40 Terminal X49/7 Analogue Output
Default value: [0] No operation
Conversion index: –
Select the functionality of terminal X49/7.
Option
Name
[0]*
No operation
[52]
MCO
[100]
Output frequency
[101]
Reference
[102]
Feedback
[103]
Motor current
[104]
Torque rel to limit
[105]
Torque relate to
rated
[106]
Power
[107]
Speed
[108]
Torque
[109]
Max out freq
Danfoss A/S © 2022.12
N O T I C E
Parameter type: Option
Data type: Uint8
Description
Indicates no signal on the analog output.
0 Hz = 0 mA; 100 Hz = 20 mA.
Parameter 3-00 Reference Range [Min - Max] 0% = 0 mA; 100% = 20 mA
Parameter 3-00 Reference Range [-Max - Max] -100% = 0 mA; 0% = 10 mA; +100% = 20 mA.
The value is taken from parameter 16-37 Inv. Max. Current. The inverter maximum current (160%
current) is equal to 20 mA.
Example: Inverter normal current (11 kW) is 24 A. 160 %=38.4 A. Motor normal current is 22 A, the
readout is 11.46 mA.
20 mA × 22 A
= 11 . 46 mA
38 . 4 A
When the normal motor current is equal to 20 mA, the output setting of parameter 6-52 Terminal
42 Output Max Scale is:
I
× 100
38 . 4 × 100
VLT, MAX
=
I
22
Motor, Nom
The torque setting is related to the setting in parameter 4-16 Torque Limit Motor Mode.
The torque is related to the motor torque setting.
Taken from parameter 1-20 Motor Power [kW].
Taken from parameter 3-03 Maximum Reference. 20 mA equals the value in parameter 3-03 Maxi-
mum Reference.
Torque reference related to 160% torque.
0 Hz = 0 mA, parameter 4-19 Max Output Frequency = 20 mA.
Setup: All setups
Change during operation: True
= 175 %
Parameter Descriptions
AU275636650261en-000101 / 130R0334 | 643
