VLT AutomationDrive FC 301/302
Programming Guide
Option
[223] On target
[224] Position limit
[225] Position error
[226] Touch on target
[227] Touch activated
[228] Touch sensor found
[229] Vir. master on ref.
[231] In power lim. mot.
[232] In power lim. gen.
[233] In power limit
[234] PE power off
204 | Danfoss A/S © 2022.12
Function
This option is only available with software version 48.XX.
Positioning is completed and the on-target signal is sent when the actual position is within pa-
rameter 3-05 On Reference Window for the duration of parameter 3-09 On Target Time and the ac-
tual speed does not exceed parameter 3-05 On Reference Window.
This option is only available with software version 48.XX.
The position error exceeds the value in parameter 4-71 Maximum Position Error for the time set in
parameter 4-72 Position Error Timeout.
This option is only available with software version 48.XX.
The position is outside the limits set in parameter 3-06 Minimum Position and parameter 3-07 Maxi-
mum Position.
This option is only available with software version 48.XX.
The target position is reached in touch probe position mode.
This option is only available with software version 48.XX.
Touch probe positioning is active. The drive monitors the touch probe sensor input.
This option is only available with software version 48.XX.
The touch sensor has been detected.
This option is only available with software version 48.XX.
The virtual master is running on the set reference.
N O T I C E
N O T I C E
N O T I C E
N O T I C E
N O T I C E
N O T I C E
N O T I C E
AU275636650261en-000101 / 130R0334
Parameter Descriptions
