Danfoss VLT AutomationDrive FC 301 Programming Manual page 193

VLT AutomationDrive FC 301/302
Programming Guide
Parameter 5-16 Terminal X30/2 Digital Input
Table 341: Parameter 5-16 Terminal X30/2 Digital Input
5-16 Terminal X30/2 Digital Input
Default value: Size related
Conversion index: –
The options for this parameter are the same as those listed for parameter 5-10 Terminal 18 Digital Input.
Parameter 5-17 Terminal X30/3 Digital Input
Table 342: Parameter 5-17 Terminal X30/3 Digital Input
5-17 Terminal X30/3 Digital Input
Default value: Size related
Conversion index: –
The options for this parameter are the same as those listed for parameter 5-10 Terminal 18 Digital Input.
Parameter 5-18 Terminal X30/4 Digital Input
Table 343: Parameter 5-18 Terminal X30/4 Digital Input
5-18 Terminal X30/4 Digital Input
Default value: Size related
Conversion index: –
The options for this parameter are the same as those listed for parameter 5-10 Terminal 18 Digital Input.
Parameter 5-19 Terminal 37 Safe Stop
Table 344: Parameter 5-19 Terminal 37 Safe Stop
5-19 Terminal 37 Safe Stop
Default value: Size related
Conversion index: –
Options [4] PTC 1 Alarm to [9] PTC 1 & Relay W/A are only available when the VLT® PTC Thermistor Card MCB 112 is connected.
Selecting Auto Reset/Warning enables automatic restart of the drive.
Use this parameter to configure the Safe Torque Off functionality. A warning message makes the drive coast the motor and enables
the automatic restart. An alarm message makes the drive coast the motor and requires a manual restart (via a fieldbus, Digital I/O, or
by pressing [RESET] on the LCP). When the VLT® PTC Thermistor Card MCB 112 is mounted, configure the PTC options to get the full
benefit from the alarm handling.
Op- Name
tion
[1] Safe stop alarm
[3] Safe stop warn-
ing
[4] PTC 1 alarm
Danfoss A/S © 2022.12
Parameter type: Option
Data type: Uint8
Parameter type: Option
Data type: Uint8
Parameter type: Option
Data type: Uint8
Parameter type: Option
Data type: Uint8
N O T I C E
N O T I C E
Description
Coasts the drive when Safe Torque Off is activated. Manual reset from LCP, digital input, or fieldbus.
Coasts the drive when Safe Torque Off is activated (terminal 37 off). When the Safe Torque Off cir-
cuit is re-established, the drive continues without manual reset.
Coasts the drive when Safe Torque Off is activated. Manual reset from LCP, digital input, or fieldbus.
Parameter Descriptions
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
Setup: 1 setup
Change during operation: True
AU275636650261en-000101 / 130R0334 | 193
