Danfoss VLT AutomationDrive FC 301 Programming Manual page 240

VLT AutomationDrive FC 301/302
Programming Guide
Option Name
[124] Speed both dir
4–20 mA
[130] Output freq. 4–
20mA
[131] Reference 4–
20mA
[132] Feedback 4–
20mA
[133] Motor cur. 4–
20mA
[134] Torq.% lim 4–
20mA
[135] Torq.% nom 4–
20mA
[136] Power 4–20mA
[137] Speed 4–20mA
[138] Torque 4–20mA
[139] Bus ctrl.
[140] Bus ctrl. 4-20mA
[141] Bus ctrl t.o.
[142] Bus ctrl 4-20mA
t.o.
[147] Main act val
[148] Main act val
4-20mA
[149] Torque % lim
4-20mA
240 | Danfoss A/S © 2022.12
Description
0 Hz = 4 mA, 100 Hz = 20 mA.
Parameter 3-00 Reference Range [Min-Max] 0% = 4 mA; 100% = 20 mA
Parameter 3-00 Reference Range [-Max-Max] -100% = 4 mA; 0% = 12 mA; +100% = 20 mA.
The value is taken from parameter 16-37 Inv. Max. Current. The inverter maximum current (160%
current) is equal to 16 mA. Example: Inverter normal current (11 kW) is 24 A. 160% = 38.4 A. Motor
normal current is 22 A, the readout is 13.17 mA.
16 mA × 22 A
= 13 . 17 mA
38.4 A
If the normal motor current is equal to 20 mA, the output setting of parameter 6-52 Terminal 42
Output Max Scale is:
I × 100 38 . 4 × 100
VLT, MAX
=
I
22
Motor, Nom
The torque setting is related to the setting in parameter 4-16 Torque Limit Motor Mode.
The torque setting is related to the motor torque setting.
Taken from parameter 1-20 Motor Power [kW].
Taken from parameter 3-03 Maximum Reference. 20 mA = value in parameter 3-03 Maximum Refer-
ence.
Torque reference related to 160% torque.
An output value set from fieldbus process data. The output works independently of internal func-
tions in the drive.
An output value set from fieldbus process data. The output works independently of internal func-
tions in the drive.
Parameter 4-54 Warning Reference Low defines the behavior of the analog output in case of fieldbus
timeout.
Parameter 4-54 Warning Reference Low defines the behavior of the analog output in case of fieldbus
timeout.
Analog output at 0 torque is 12 mA. Motoring torque increases the output current to maximum
torque limit 20 mA (set in parameter 4-16 Torque Limit Motor Mode). Generating torque decreases
the output to torque limit in generator mode (set in parameter 4-17 Torque Limit Generator Mode)
Example: Parameter 4-16 Torque Limit Motor Mode = 200% and parameter 4-17 Torque Limit Genera-
tor Mode = 200%. 20 mA = 200% motoring and 4 mA = 200% generating.
= 175 %
Parameter Descriptions
AU275636650261en-000101 / 130R0334
