VLT AutomationDrive FC 301/302
Programming Guide
Parameter 36-44 Terminal X49/7 Bus Ctrl
Table 1334: Parameter 36-44 Terminal X49/7 Bus Ctrl
36-44 Terminal X49/7 Bus Ctrl
Default value: 0%
Conversion index: 0
This parameter contains the output level of terminal X49/7 if the terminal is controlled by bus.
Parameter 36-45 Terminal X49/7 Timeout Preset
Table 1335: Parameter 36-45 Terminal X49/7 Timeout Preset
36-45 Terminal X49/7 Timeout Preset
Default value: 0%
Conversion index: 0
The drive sends the value of this parameter to the output terminal when the terminal is controlled by a fieldbus and a timeout is
detected.
5.29.6 36-5* Output X49/9
Use the parameters in this group to configure the mode of inputs and outputs of VLT® Programmable I/O MCB 115.
The following parameter is only available in FC 302:
-
Parameter 36-51 Terminal X49/9 Digital Output.
Parameter 36-50 Terminal X49/9 Analogue Output
Table 1336: Parameter 36-50 Terminal X49/9 Analogue Output
36-50 Terminal X49/9 Analogue Output
Default value: [0] No operation
Conversion index: –
Select the functionality of terminal X49/9.
Option Name
[0]* No operation
[52] MCO
[100] Output frequency
[101] Reference
[102] Feedback
[103] Motor current
Danfoss A/S © 2022.12
Parameter type: Range, 0 - 100%
Data type: N2
Parameter type: Range, 0 - 100%
Data type: Uint16
N O T I C E
Parameter type: Option
Data type: Uint8
Description
Indicates no signal on the analog output.
0 Hz = 0 mA; 100 Hz = 20 mA.
Parameter 3-00 Reference Range [Min - Max] 0% = 0 mA; 100% = 20 mA
Parameter 3-00 Reference Range [-Max - Max] -100% = 0 mA; 0% = 10 mA; +100% = 20 mA.
The value is taken from parameter 16-37 Inv. Max. Current. The inverter maximum current (160%
current) is equal to 20 mA.
Example: Inverter normal current (11 kW) is 24 A. 160 %=38.4 A. Motor normal current is 22 A, the
readout is 11.46 mA.
Parameter Descriptions
Setup: All setups
Change during operation: True
Setup: 1 setup
Change during operation: True
Setup: All setups
Change during operation: True
