Option Function
This option selects between absolute and relative positioning. The option is valid for the next position-
ing command.
[113] Enable refer-
ence
Positioning mode: The drive activates the selected positioning type and target, and starts the motion
towards the new target. The motion starts either immediately or when active positioning is completed,
depending on the settings of parameter 17-90 Absolute Position Mode and parameter 17-91 Relative Posi-
tion Mode.
Synchronization mode: High signal locks the actual follower position to the actual master position. The
follower starts and catches up with the master. Low signal stops the synchronization and the follower
makes a controlled stop.
[114] Sync. to pos.
mode
Select positioning in synchronization mode.
[115] Home sensor
Normally-open contact for defining the home position. The function is defined in parameter 17-80
Homing Function.
[116] Home sensor
inv.
Normally-closed contact for defining the home position. The function is defined in parameter 17-80
Homing Function.
[117] Touch sensor
Normally-open contact. Serves as a reference for touch probe positioning.
[118] Touch sensor
inv
Normally-closed contact. Serves as a reference for touch probe positioning.
[119] Speed mode
186 | Danfoss A/S © 2022.12
This option is only available with software version 48.XX.
This option is only available with software version 48.XX.
This option is only available with software version 48.XX.
This option is only available with software version 48.XX.
This option is only available with software version 48.XX.
This option is only available with software version 48.XX.
This option is only available with software version 48.XX.
N O T I C E
N O T I C E
N O T I C E
N O T I C E
N O T I C E
N O T I C E
N O T I C E
