VLT AutomationDrive FC 301/302
Programming Guide
Bit Hex Dec
11 00000800 2048
12 00001000 4096
13 00002000 8192
14 00004000 16384
15 00008000 32768
16 00010000 65536
17 00020000 131072
18 00040000 262144
19 00080000 524288
20 00100000 1048576
21 00200000 2097152
22 00400000 4194304
23 00800000 8388608
24 01000000 16777216
25 02000000 33554432
26 04000000 67108864
27 08000000 134217728
28 10000000 268435456
Danfoss A/S © 2022.12
Ext. status word
Parameter 16-94 Ext. Status Word
speed <parameter 4-52 Warning Speed Low
Brake check OK
brake test NOT OK
Braking max.
BrakePower > Brakepowerlimit (2-12)
Braking
Out of speed range
OVC active
AC brake
Password timelock
number of allowed password trials exceeded - timelock
active
Password protection
0-61 = ALL_NO_ACCESS OR
BUS_NO_ACCESS OR
BUS_READONLY
Reference high
reference >parameter 4-55 Warning Reference High
Reference low
reference <parameter 4-54 Warning Reference Low
Local reference
reference site = REMOTE -> auto on pressed & active
Protection mode notification
Unused
Unused
Unused
Unused
Unused
Unused
Troubleshooting
Ext. status word 2 Ext. status
word 3
Parameter 16-95 Ext. Parameter
Status Word 2 16-99 Ext.
Status Word 3
Stop –
Standby –
Freeze output re- –
quest
Freeze output –
Jog request –
Jog –
Start request –
Start –
Start applied –
Start delay –
Sleep –
Sleep boost –
Running/pipe filling –
Drive bypass –
Emergency mode –
External interlock –
Emerg. m limit excee- –
ded
FlyStart active –
