Op- Name
tion
[5] PTC 2 warning
[6] PTC 1 & Relay A
[7] PTC 1 & Relay W
[8] PTC 1 & Relay
A/W
[9] PTC 1 & Relay
W/A
Table 345: Overview of Functions, Alarms, and Warnings
Function
No function
Safe Torque Off alarm
Safe Torque Off warning
W means warning and A means alarm.
1
A dangerous failure related to STO issues alarm 72, Dangerous Failure.
Parameter 5-20 Terminal X46/1 Digital Input
Table 346: Parameter 5-20 Terminal X46/1 Digital Input
5-20 Terminal X46/1 Digital Input
Default value: [0] No operation
Conversion index: –
All functions are described in
Option Name
[0]* No operation
[1] Reset
[2] Coast inverse
[3] Coast and reset inv
[4] Quick stop inverse
[5] DC-brake inverse
[6] Stop inverse
[8] Start
194 | Danfoss A/S © 2022.12
Description
Coasts the drive when Safe Torque Off is activated (terminal 37 off). When the Safe Torque Off cir-
cuit is re-established, the drive continues without manual reset, unless a digital input set to [80] PTC
Card 1 is still enabled.
This option is used when the VLT® PTC Thermistor Card MCB 112 gates with a stop key through a
safety relay to terminal 37. Coasts the drive when Safe Torque Off is activated. Manual reset from
LCP, digital input, or fieldbus.
This option is used when the VLT® PTC Thermistor Card MCB 112 gates with a stop key through a
safety relay to terminal 37. Coasts the drive when Safe Torque Off is activated (terminal 37 off).
When the Safe Torque Off circuit is re-established, the drive continues without manual reset, unless
a digital input set to [80] PTC Card 1 is still enabled.
This option enables using a combination of alarm and warning.
This option enables using a combination of warning and alarm.
Number
[0]
[1]*
[3]
Parameter type: Option
Data type: Uint8
Table 328, Table 330, Table 332, and
PTC Relay
– –
– Safe Torque Off [A68
– Safe Torque Off [W68
Setup: All setups
Change during operation: True
Table 334.
Description
Parameter Descriptions
]
(1)
]
(1)
