VLT AutomationDrive FC 301/302
Programming Guide
5.31.5 42-4* SS1
Parameter 42-40 Type
Table 1388: Parameter 42-40 Type
42-40 Type
Default value: [0] Delay
Conversion index: -
Use this parameter to select the type of SS1 safety function.
Option
[0]*
[1]
[2]
Parameter 42-41 Ramp Profile
Table 1389: Parameter 42-41 Ramp Profile
42-41 Ramp Profile
Default value: [0] Linear
Conversion index: -
Option
[0]*
[2]
Parameter 42-42 Delay Time
Table 1390: Parameter 42-42 Delay Time
42-42 Delay Time
Default value: 1 s
Conversion index: 0
Configure the time during which STO must be activated.
Parameter 42-43 Delta T
Table 1391: Parameter 42-43 Delta T
42-43 Delta T
Default value: 2%
Conversion index: 0
T subtracts from the time in parameter 42-42 Delay Time to get the motor to stop before the timer expires.
Danfoss A/S © 2022.12
Parameter type: Option
Data type: Uint8
Name
Delay
Ramp (slope)
Ramp (time)
Parameter type: Option
Data type: Uint8
Name
Linear
S-ramp const time
Parameter type: Range, 0.1 - 3600 s
Data type: Uint16
Parameter type: Range, 0 - 99%
Data type: Uint8
Parameter Descriptions
Setup: All setups
Change during operation: False
Description
Setup: All setups
Change during operation: False
Description
Setup: All setups
Change during operation: False
Setup: All setups
Change during operation: False
AU275636650261en-000101 / 130R0334 | 673
