Danfoss VLT AutomationDrive FC 301 Programming Manual page 522

VLT AutomationDrive FC 301/302
Programming Guide
Parameter 17-51 Input Voltage
Table 930: Parameter 17-51 Input Voltage
17-51 Input Voltage
Default value: 7 V
Conversion index: -1
Set the input voltage to the resolver. The voltage is stated as RMS value. The value is stated in the datasheet for resolvers.
Parameter 17-52 Input Frequency
Table 931: Parameter 17-52 Input Frequency
17-52 Input Frequency
Default value: 10 kHz
Conversion index: 2
Set the input frequency to the resolver. The value is stated in the datasheet for resolvers.
Parameter 17-53 Transformation Ratio
Table 932: Parameter 17-53 Transformation Ratio
17-53 Transformation Ratio
Default value: 0.5
Conversion index: -1
Set the transformation ratio for the resolver. The transformation ratio is:
V
out
T =
ratio
V
in
The value is stated in the datasheet for resolvers.
Parameter 17-56 Encoder Sim. Resolution
Table 933: Parameter 17-56 Encoder Sim. Resolution
17-56 Encoder Sim. Resolution
Default Value: [0] Disabled
Conversion Index: -
Set the resolution and activate the encoder emulation function (generation of encoder signals from the measured position from a
resolver). Use this function to transfer the speed or position information from 1 drive to another. To disable the function, select [0]
Disabled.
Option Name
[0]* Disabled
[1] 512
[2] 1024
[3] 2048
[4] 4096
[5] Enable encoder sim. adv.
522 | Danfoss A/S © 2022.12
Parameter type: Range, 2 - 8 V
Data type: Uint8
Parameter type: Range, 2 - 15 kHz
Data type: Uint8
Parameter type: Range, 0.1 - 1.1
Data type: Uint8
Parameter Type: Option
Data Type: Uint8
Description
Set the encoder simulation resolution via parameter 17-58 Encoder Sim. Resolution Adv.
Parameter Descriptions
Setup: 1 setup
Change during operation: False
Setup: 1 setup
Change during operation: False
Setup: 1 setup
Change during operation: False
Setup: All setups
Change during operation: False
AU275636650261en-000101 / 130R0334
