Option Name
[58] Actual position
[59] Actual position
4–20 mA
[100] Output frequen-
cy
[101] Reference
[102] Feedback
[103] Motor current
[104] Torque rel to lim-
it
[105] Torque relate to
rated
[106] Power
[107] Speed
[108] Torque
[109] Max out freq
[113] PID clamped out-
put
[119] Torque % lim
[123] Speed both dir
Danfoss A/S © 2022.12
Description
This option is available only with software version 48.XX.
The actual position. 0–20 mA corresponds to parameter 3-06 Minimum Position to parameter 3-07
Maximum Position.
This option is available only with software version 48.XX.
The actual position. 4–20 mA corresponds to parameter 3-06 Minimum Position to parameter 3-07
Maximum Position.
0 Hz = 0 mA; 100 Hz = 20 mA.
Parameter 3-00 Reference Range [Min - Max] 0% = 0 mA; 100% = 20 mA
Parameter 3-00 Reference Range [-Max - Max] -100% = 0 mA; 0% = 10 mA; +100% = 20 mA.
The value is taken from parameter 16-37 Inv. Max. Current. The inverter maximum current (160%
current) is equal to 20 mA.
Example: Inverter normal current (11 kW) is 24 A. 160 %=38.4 A. Motor normal current is 22 A, the
readout is 11.46 mA.
20 mA × 22 A
= 11 . 46 mA
38.4 A
When the normal motor current is equal to 20 mA, the output setting of parameter 6-52 Terminal 42
Output Max Scale is:
I × 100 38 . 4 × 100
VLT, MAX
=
I 22
Motor, Nom
The torque setting is related to the setting in parameter 4-16 Torque Limit Motor Mode.
The torque is related to the motor torque setting.
Taken from parameter 1-20 Motor Power [kW].
Taken from parameter 3-03 Maximum Reference. 20 mA equals the value in parameter 3-03 Maxi-
mum Reference.
Torque reference related to 160% torque.
0 Hz = 0 mA, parameter 4-19 Max Output Frequency = 20 mA.
N O T I C E
N O T I C E
= 175 %
