VLT AutomationDrive FC 301/302
Programming Guide
Option Name
[17] Analog input AICCT
[18] Pulse input FI29
[19] Pulse input FI33
[20] Alarm number
[21] Warning number
[22] Analog input X30/11
[23] Analog input X30/12
[30] Counter A
[31] Counter B
[32] Process PID error
[33] Process PID Output
[34] Analog input X48/2
[35] Temp input X48/4
[36] Temp input X48/7
[37] Temp input X48/10
[39] Safe opt. speed error
[43] Analog input X49/1
[44] Analog input X49/3
382 | Danfoss A/S © 2022.12
Description
Value is in [°]. AICCT is control card temperature.
This option is only available in FC 302.
The value is in %.
The value is in %.
Shows the actual alarm number.
With this selection, it is not possible to use < and > as comparator operators.
Several alarms/warnings can be present at the same time. As the alarm/warning numbers
are not grouped in a predefined order, defining a range is not relevant.
Shows the actual warning number.
With this selection, it is not possible to use < and > as comparator operators.
Several alarms/warnings can be present at the same time. As the alarm/warning numbers
are not grouped in a predefined order, defining a range is not relevant.
Value of the PID error (parameter 18-90 Process PID Error).
Value of the PID output (parameter 18-91 Process PID Output).
N O T I C E
N O T I C E
N O T I C E
N O T I C E
N O T I C E
AU275636650261en-000101 / 130R0334
Parameter Descriptions
