VLT AutomationDrive FC 301/302
Programming Guide
Parameter 3-36 CAM Master Table
Table 218: Parameter 3-36 CAM Master Table
3-36 CAM Master Table
Default value: 0 Parameter type: Range, -2147483648 - 2147483647
Conversion index: 0 Data type: Int32, Array [20]
This parameter is only available with software version 48.XX.
Master position which together with the corresponding element of parameter 3-37 CAM Follower Table forms a CAM position point.
Parameter 3-37 CAM Follower Table
Table 219: Parameter 3-37 CAM Follower Table
3-37 CAM Follower Table
Default value: 0 Parameter type: Range, -2147483648 - 2147483647 [AbsolutePositionU-
nit]
Conversion index: 0 Data type: Int32, Array [20]
This parameter is only available with software version 48.XX.
Follower position which together with the corresponding element of parameter 3-36 CAM Master Table forms a CAM position point.
Parameter 3-38 CAM Curve Table
Table 220: Parameter 3-38 CAM Curve Table
3-38 CAM Curve Table
Default value: [0] None
Conversion index: 0
This parameter is only available with software version 48.XX.
Option Name Description
[0]* None
[1] Linear
Connects the CAM table point with a straight line, corresponds to a fixed gear ratio between master and
follower.
[2] Poly x'order
Connects the CAM table points with an x-order polynomial where x is determined by the number of con-
secutive points of this type.
[3] Poly 2'order
Connects the CAM table points with a 2
[4] Poly 3'order
Connects the CAM table points with a 3
[5] Poly 4'order
Connects the CAM table points with a 4
this type are required to use this selection.
Danfoss A/S © 2022.12
N O T I C E
N O T I C E
Parameter type: Option
Data type: Uint8, Array [20]
N O T I C E
nd
rd
order polynomial.
th
order polynomial. At least 2 consecutive CAM table points of
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
order polynomial.
AU275636650261en-000101 / 130R0334 | 141
Parameter Descriptions
Setup: All setups
Change during operation: True
