VLT AutomationDrive FC 301/302
Programming Guide
Parameter 5-10 Terminal 18 Digital Input
Table 335: Parameter 5-10 Terminal 18 Digital Input
5-10 Terminal 18 Digital Input
Default value: Size related
Conversion index: –
Select the function from the available digital input range and the additional options [60] Counter A (up), [61] Counter A (down), [63]
Counter B (up), and [64] Counter B (down). Counters are used in smart logic control functions. All functions are described in
Table 330, Table 332, and Table
Option Name
[0] No operation
[1] Reset
[2] Coast inverse
[3] Coast and reset inv
[4] Quick stop inverse
[5] DC-brake inverse
[6] Stop inverse
[8] Start
[9] Latched
[10] Reversing
[11] Start reversing
[12] Enable start forward
[13] Enable start reverse
[14] Jog
[15] Preset reference on
[16] Preset ref bit 0
[17] Preset ref bit 1
[18] Preset ref bit 2
[19] Freeze reference
[20] Freeze output
[21] Speed up
[22] Speed down
[23] Set-up select bit 0
[24] Set-up select bit 1
[26] Precise stop inverse
[27] Precise start, stop
Danfoss A/S © 2022.12
Parameter type: Option
Data type: Uint8
334.
Parameter Descriptions
Setup: All setups
Change during operation: True
Description
AU275636650261en-000101 / 130R0334 | 189
Table 328,
