VLT AutomationDrive FC 301/302
Programming Guide
Parameter 32-07 Absolute Encoder Clock Generation
Table 1118: Parameter 32-07 Absolute Encoder Clock Generation
32-07 Absolute Encoder Clock Generation
Default value: [1] On
Conversion index: -
Option Name Description
[0] Off
Select [0] Off when more MCOs are connected to the same absolute encoder. Only 1 MCO is allowed to gener-
ate the clock signal when multiple MCOs are interconnected.
[1]* On Select [1] On when 1 MCO is connected to 1 absolute encoder.
Parameter 32-08 Absolute Encoder Cable Length
Table 1119: Parameter 32-08 Absolute Encoder Cable Length
32-08 Absolute Encoder Cable Length
Default value: 0
Conversion index: 0
Set the total cable length (in meters) to avoid that the absolute encoder (SSI) signals come out of synchronization due to signal
delays caused by long encoder cables. VLT® Motion Control Option MCO 305 and VLT® Motion Control Option MCO 302 compen-
sate for the cable delay when the cable length is known.
Parameter 32-09 Encoder Monitoring
Table 1120: Parameter 32-09 Encoder Monitoring
32-09 Encoder Monitoring
Default value: [0] Off
Conversion index: -
Option
[0]*
[1]
[2]
[3]
[4]
Parameter 32-10 Rotational Direction
Table 1121: Parameter 32-10 Rotational Direction
32-10 Rotational Direction
Default value: [1] No action
Conversion index: -
Normally, a positive reference value brings about a positive change of the position. If this is not the case, the reference value can be
reversed internally.
590 | Danfoss A/S © 2022.12
Parameter type: Option
Data trype: Uint8
Parameter type: Range, 0 - 300 m
Data type: Uint16
Parameter type: Option
Data type: Uint8
Name
Off
3 channels
2 channels
Warning
Alarm
Parameter type: Option
Data type: Uint8
Parameter Descriptions
Setup: 2 setups
Change during operation: True
Setup: 2 setups
Change during operation: True
Setup: 2 setups
Change during operation: True
Description
Setup: 2 setups
Change during operation: True
AU275636650261en-000101 / 130R0334
