Option Name
[113] PID clamped out-
put
[117] Shaft power
[119] Torque % lim
[123] Speed both dir
[135] Torq.% nom 4–
20mA
[139] Bus ctrl
[141] Bus ctrl t.o.
[147] Main act val
[158] Motor Volt.
Parameter 36-41 Terminal X49/7 Digital Output
Table 1331: Parameter 36-41 Terminal X49/7 Digital Output
36-41 Terminal X49/7 Digital Output
Default value: [0] No operation
Conversion index: –
Option Name
[0]* No operation
[1] Control ready
[2] Drive ready
[3] Drive rdy/rem ctrl
[4] Enable/no warning
[5] Running
[6] Running/no warning
[7] Run in range/no warn
[8] Run on ref/no warn
[9] Alarm
[10] Alarm or warning
[11] At torque limit
[12] Out of current range
[13] Below current, low
[14] Above current, high
644 | Danfoss A/S © 2022.12
Description
The torque setting is related to the motor torque setting.
An output value set from fieldbus process data. The output works independently of internal func-
tions in the drive.
Parameter 4-54 Warning Reference Low defines the behavior of the analog output in case of field-
bus timeout.
Parameter type: Option
Data type: Uint8
Parameter Descriptions
Setup: All setups
Change during operation: True
Description
AU275636650261en-000101 / 130R0334
