VLT AutomationDrive FC 301/302
Programming Guide
Option
Name
[1657]
Feedback [RPM]
[1660]
Digital input
[1661]
Terminal 53 switch setting
[1662]
Analog input 53
[1663]
Terminal 54 switch setting
[1664]
Analog input 54
[1665]
Analog output 42 [mA]
[1666]
Digital output [bin]
[1667]
Freq. input #29 [Hz]
[1668]
Freq. input #33 [Hz]
[1669]
Pulse output #27 [Hz]
[1670]
Pulse output #29 [Hz]
[1671]
Relay output [bin]
[1672]
Counter A
[1673]
Counter B
[1674]
Prec. stop counter
[1675]
Analog in X30/11
[1676]
Analog in X30/12
[1677]
Analog out X30/8 [mA]
[1678]
Analog out X45/1 [mA]
[1679]
Analog out X45/3 [mA]
[1684]
Comm. option STW
[1687]
Bus readout alarm/warning
[1689]
Configurable alarm/warning word
[1690]
Alarm word
[1691]
Alarm word 2
[1692]
Warning word
[1693]
Warning word 2
[1694]
Ext. status word
[1695]
Ext. status word 2
[1696]
Maintenance word
[1697]
Alarm word 3
Danfoss A/S © 2022.12
Parameter Descriptions
Description
AU275636650261en-000101 / 130R0334 | 345
