Op- Name Description
tion
[0]* Target posi- The drive uses the latest target position as reference for the new positioning command. The drive exe-
tion cutes the new positioning command immediately without completing the previous positioning. The
new target is calculated with the formula: New target = previous target + position reference.
[1] Buffered tar- The drive uses the latest target position as reference for the new positioning command. The drive exe-
get pos. cutes the new positioning command when it completes the previous command. Only 1 positioning
command can be buffered at a time.
[2] Comman- The drive uses the commanded position as reference for the new positioning command. The drive exe-
ded position cutes the new positioning command immediately without completing the previous positioning. The
new target is calculated with the formula: New target = commanded position + position reference.
[3] Actual posi- The drive uses the actual position as reference for the new positioning command. The drive executes the
tion new positioning command immediately without completing the previous positioning. The new target is
calculated with the formula: New target = actual position + position reference.
Parameter 17-92 Position Control Selection
Table 961: Parameter 17-92 Position Control Selection
17-92 Position Control Selection
Default value: [0] No operation
Conversion index: -
This parameter is only available with software version 48.XX.
This parameter allows to select the position control mode without using a digital input signal or a fieldbus bit.
Op- Name
tion
[0]* No operation
[1] Relative posi-
tion
[2] Enable refer-
ence
Parameter 17-93 Master Offset Selection
Table 962: Parameter 17-93 Master Offset Selection
17-93 Master Offset Selection
Default value: [0] Absolute enabled
Conversion index: -
This parameter is only available with software version 48.XX.
Select the behavior of the master offset in synchronization mode.
Danfoss A/S © 2022.12
Parameter type: Option
Data type: Uint8
N O T I C E
Description
Use a digital input signal or a fieldbus bit to activate the enable-reference mode and the relative posi-
tion mode.
This option selects the relative position mode permanently. All positioning commands are consid-
ered to be relative. Toggling option [113] Enable Reference on a digital input or the enable reference
fieldbus bit triggers relative positioning.
This option selects the enable-reference mode permanently. Any new position reference triggers an
absolute positioning command with the selected position reference as target. This option cannot be
used with relative positioning.
Parameter type: Option
Data type: Uint8
N O T I C E
Parameter Descriptions
Setup: All setups
Change during operation: False
Setup: All setups
Change during operation: False
