VLT AutomationDrive FC 301/302
Programming Guide
Option Name
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL time-out 3
[71] SL time-out 4
[72] SL time-out 5
[73] SL time-out 6
[74] SL time-out 7
[75] Start command given
[76] Digital input X30/2
[77] Digital input X30/3
[78] Digital input X30/4
[79] Digital input X46/1
[80] Digital input X46/3
[81] Digital input X46/5
[82] Digital input X46/7
[83] Digital input X46/9
[84] Digital input X46/11
[85] Digital input X46/13
[90] ATEX ETR cur. warning
[91] ATEX ETR cur. alarm
[92] ATEX ETR freq. warning
[93] ATEX ETR freq. alarm
[94] RS Flipflop 0
[95] RS Flipflop 1
[96] RS Flipflop 2
[97] RS Flipflop 3
[98] RS Flipflop 4
[99] RS Flipflop 5
406 | Danfoss A/S © 2022.12
Description
Use the result of comparator 4.
Use the result of comparator 5.
Use the result of logic rule 4.
Use the result of logic rule 5.
Available if parameter 1-90 Motor Thermal Protection is set to [20] ATEX ETR or [21] Advanced
ETR. If alarm 164, ATEX ETR cur.lim.alarm is active, the output is 1.
Available if parameter 1-90 Motor Thermal Protection is set to [20] ATEX ETR or [21] Advanced
ETR. If alarm 166, ATEX ETR freq.lim.alarm is active, the output is 1.
Available if parameter 1-90 Motor Thermal Protection is set to [20] ATEX ETR or [21] Advanced
ETR. If alarm 163, ATEX ETR cur.lim.warning is active, the output is 1.
Available if parameter 1-90 Motor Thermal Protection is set to [20] ATEX ETR or [21] Advanced
ETR. If warning 165, ATEX ETR freq.lim.warning is active, the output is 1.
See parameter group 13-1* Comparators.
See parameter group 13-1* Comparators.
See parameter group 13-1* Comparators.
See parameter group 13-1* Comparators.
See parameter group 13-1* Comparators.
See parameter group 13-1* Comparators.
Parameter Descriptions
