VLT AutomationDrive FC 301/302
Programming Guide
Parameter 17-58 Encoder Sim. Resolution Adv.
Table 934: Parameter 17-58 Encoder Sim. Resolution Adv.
17-58 Encoder Sim. Resolution Adv.
Default value: 0
Conversion index: 0
Set the encoder simulation resolution as a continuous value in steps of 1. This parameter is only active when [5] Enable encoder sim.
adv. is selected in parameter 17-56 Encoder Sim. Resolution.
Parameter 17-59 Resolver Interface
Table 935: Parameter 17-59 Resolver Interface
17-59 Resolver Interface
Default value: [0] Disabled
Conversion index: -
Activate the VLT® Resolver Input MCB 103 when the resolver parameters are selected. To avoid damage to resolvers, adjust parame-
ter 17-50 Poles and parameter 17-53 Transformation Ratio before enabling this parameter.
Option
[0]*
[1]
5.17.6 17-6* Monitoring and Application
The following parameters are only available in FC 302:
-
Parameter 17-67 Raw Inc. Quad Counter
-
Parameter 17-68 Raw Abs. Pos. Low
-
Parameter 17-69 Raw Abs. Pos. High
This parameter group is for selecting extra functions when VLT® Encoder MCB 102 or VLT® Resolver Input MCB 103 is fitted into
option slot B as speed feedback. Monitoring and application parameters cannot be adjusted while the motor is running.
Parameter 17-60 Feedback Direction
Table 936: Parameter 17-60 Feedback Direction
17-60 Feedback Direction
Default value: [0] Clockwise
Conversion index: -
This parameter cannot be adjusted while the motor is running.
Change the detected encoder rotation direction without changing the wiring to the encoder.
Danfoss A/S © 2022.12
Parameter type: Range, 0 - 16384
Data type: Uint16
Parameter type: Option
Data type: Uint8
Name
Disabled
512
N O T I C E
Parameter type: Option
Data type: Uint8
N O T I C E
Parameter Descriptions
Setup: 1 setup
Change during operation: False
Setup: All setups
Change during operation: False
Description
Setup: All setups
Change during operation: False
AU275636650261en-000101 / 130R0334 | 523
