VLT AutomationDrive FC 301/302
Programming Guide
Parameter 36-30 Terminal X49/5 Low Voltage
Table 1323: Parameter 36-30 Terminal X49/5 Low Voltage
36-30 Terminal X49/5 Low Voltage
Default value: 0.07 V
Conversion index: 0
Parameter 36-31 Terminal X49/3 Low Current
Table 1324: Parameter 36-31 Terminal X49/3 Low Current
36-31 Terminal X49/3 Low Current
Default value: 4 mA
Conversion index: -3
Parameter 36-32 Terminal X49/5 High Voltage
Table 1325: Parameter 36-32 Terminal X49/5 High Voltage
36-32 Terminal X49/5 High Voltage
Default value: 10 V
Conversion index: 0
Parameter 36-33 Terminal X49/5 High Current
Table 1326: Parameter 36-33 Terminal X49/5 High Current
36-33 Terminal X49/5 High Current
Default value: 20 mA
Conversion index: -3
Parameter 36-34 Terminal X49/5 Low Ref./Feedb. Value
Table 1327: Parameter 36-34 Terminal X49/5 Low Ref./Feedb. Value
36-34 Terminal X49/5 Low Ref./Feedb. Value
Default value: 0 ReferenceFeedbackUnit
Conversion index: 0
Parameter 36-35 Terminal X49/5 High Ref./Feedb. Value
Table 1328: Parameter 36-35 Terminal X49/5 High Ref./Feedb. Value
36-35 Terminal X49/5 High Ref./Feedb. Value
Default value: 100 ReferenceFeedbackU-
nit
Conversion index: 0
Parameter 36-36 Term. X49/5 Filter Time Constant
Table 1329: Parameter 36-36 Term. X49/5 Filter Time Constant
36-36 Term. X49/5 Filter Time Constant
Default value: 0.001 s
Conversion index: 0
642 | Danfoss A/S © 2022.12
Parameter type: Range, 0 - 10 V
Data type: Int16
Parameter type: Range, 0 - 20 mA
Data type: Int16
Parameter type: Range, 0 - 10 V
Data type: Int16
Parameter type: Range, 0 - 20 mA
Data type: Int16
Parameter type: Range, -999999.999 - 999999.999
ReferenceFeedbackUnit
Data type: Int32
Parameter type: Range, -999999.999 - 999999.999
ReferenceFeedbackUnit
Data type: Int32
Parameter type: Range, 0.001 - 10 s
Data type: Uint16
Parameter Descriptions
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
AU275636650261en-000101 / 130R0334
