VLT AutomationDrive FC 301/302
Programming Guide
Option Name
[3664] Terminal X49/11 bus control
[4029] B-EMF protection log readout
[4280] Safe option status
[4282] Safe control word
[4283] Safe status word
[4285] Active safe func.
[4287] Time until manual test
Parameter 8-42 PCD Write Configuration
Table 520: Parameter 8-42 PCD Write Configuration
8-42 PCD Write Configuration
Default value: Size related
Conversion index: 0
Select the parameters to be assigned to the telegrams of the PCD. The number of available PCDs depends on the telegram type. The
values in the PCDs are then written to the selected parameters as data values.
Parameter 8-43 PCD Read Configuration
Table 521: Parameter 8-43 PCD Read Configuration
8-43 PCD Read Configuration
Default value: Size related
Conversion index: 0
Select the parameters to be assigned to the PCDs of the telegrams. The number of available PCDs depends on the telegram type.
PCDs contain the actual data values of the selected parameters.
Block Transfer Mode (BTM)
When Block Transfer Mode (BTM) is enabled, the parameters are written into a temporary buffer in the drive via the fieldbus. After
wiring all the required parameters to the drive in BTM mode, a Commit command is sent to the drive. The drive ensures correct
adaptation of the parameters.
Parameter 8-45 BTM Transaction Command
Table 522: Parameter 8-45 BTM Transaction Command
8-45 BTM Transaction Command
Default value: [0] Off
Conversion index: –
This parameter cannot be adjusted while the motor is running.
Option Name
[0]* Off
[1] Write to active setup
296 | Danfoss A/S © 2022.12
Parameter type: Range, 0 - 9999, Array [64]
Data type: Uint16
Parameter type: Range, 0 - 9999, Array [64]
Data type: Uint16
Parameter type: Option
Data type: Uint8
N O T I C E
Description
Parameter Descriptions
Description
Setup: 2 setups
Change during operation: True
Setup: 2 setups
Change during operation: True
Setup: All setups
Change during operation: False
AU275636650261en-000101 / 130R0334
