VLT AutomationDrive FC 301/302
Programming Guide
Parameter 6-53 Term 42 Output Bus Ctrl
Table 427: Parameter 6-53 Term 42 Output Bus Ctrl
6-53 Term 42 Output Bus Ctrl
Default value: 0%
Conversion index: -2
Holds the level of output 42 if controlled by bus.
Parameter 6-54 Term 42 Output Timeout Preset
Table 428: Parameter 6-54 Term 42 Output Timeout Preset
6-54 Term 42 Output Timeout Preset
Default value: 0%
Conversion index: -2
Holds the preset level of output 42. If a timeout function is selected in parameter 6-50 Terminal 42 Output, the output is preset to this
level if a fieldbus timeout occurs.
Parameter 6-55 Analog Output Filter
Table 429: Parameter 6-55 Analog Output Filter
6-55 Analog Output Filter
Default value: [0] Off
Conversion index: –
The following readout parameters from selection in parameter 6-50 Terminal 42 Output have a filter selected when parameter 6-55
Analog Output Filter is on.
Table 430: Readout Parameters
Selection
Motor current (I )
max
Torque limit (0–T )
lim
Rated torque (0–T )
nom
Power (0–P
nom)
Speed (0–Speed )
max
Option
[0]*
[1]
5.7.7 6-6* Analog Output 2 MCB 101
Analog outputs are current outputs: 0/4–20 mA. Common terminal (terminal X30/8) is the same terminal and electrical potential for
analog common communication. Resolution on analog output is 12 bit.
242 | Danfoss A/S © 2022.12
Parameter type: Range, 0 - 100%
Data type: N2
Parameter type: Range, 0 - 100%
Data type: Uint16
Parameter type: Option
Data type: Uint8
Name
Off
On
Setup: All setups
Change during operation: True
Setup: 1 setup
Change during operation: True
Setup: 1 setup
Change during operation: True
0–20 mA
[103]
[104]
[105]
[106]
[107]
Description
Filter off.
Filter on.
AU275636650261en-000101 / 130R0334
Parameter Descriptions
4–20 mA
[133]
[134]
[135]
[136]
[137]
