VLT AutomationDrive FC 301/302
Programming Guide
Option Name
[11] Start homing
[12] Activate touch
[13] Sync. to pos
mode
[14] Ramp 2
[15] Relay 1
[16] Relay 2
[17] Speed mode
[18] Enable vir. master
[19] Enable mast. off-
set
[20] Control word tog-
gle command
280 | Danfoss A/S © 2022.12
Description
This option is only available with software version 48.XX.
Starts the homing function selected in parameter 17-80 Homing Function. Must remain high until
homing is done, otherwise homing is aborted.
This option is only available with software version 48.XX.
Activates monitoring of the touch sensor input.
This option is only available with software version 48.XX.
Select positioning in synchronization mode.
This option is only available with software version 48.XX.
Select between ramp 1 (parameter group 3-4* Ramp 1) and ramp 2 (parameter group 3-5* Ramp 2).
Control relay 1.
Control relay 1.
This option is only available with software version 48.XX.
Select the speed mode when [9] Positioning or [10] Synchronization is selected in parameter 1-00
Configuration Mode. Speed reference is set by reference resource 1 or fieldbus REF1 relative to
parameter 3-03 Maximum Reference.
This option is only available with software version 48.XX.
Enable the signal for the virtual master function. The option is applicable when [10] Synchroniza-
tion is selected in parameter 1-00 Configuration Mode.
This option is only available with software version 48.XX.
Activates the master offset selected in parameter 3-26 Master Offset when parameter 17-93 Master
Offset Selection has a selection from [1] Absolute to [5] Relative Touch Sensor.
Changes the sign of the set target position. For example, if the set target is 1000, the activation of
this option changes the value to -1000.
N O T I C E
N O T I C E
N O T I C E
N O T I C E
N O T I C E
N O T I C E
N O T I C E
AU275636650261en-000101 / 130R0334
Parameter Descriptions
