VLT AutomationDrive FC 301/302
Programming Guide
# Alarm title
13 Over current
14 Earth (ground) fault
16 Short circuit
18 Start failed
25 Brake resistor
26 Brake overload
27 Brake IGBT
28 Brake check
30 U phase loss
31 V phase loss
32 W phase loss
36 Mains failure
37 Phase imbalance
44 Earth (ground) fault AL44
45 Earth (ground) fault 2
59 Current
If an alarm has 2 states (warning/alarm), it only triggers a service log record when going into the alarm state.
5.15.8 15-2* Historic Log
View up to 50 logged data items via the array parameters in this parameter group. Data is logged every time an event occurs (not to
be confused with SLC events). Events in this context are defined as a change in 1 of the following areas:
• Digital inputs
• Digital outputs
• Warning word
• Alarm word
• Status word
• Control word
• Extended status word
Events are logged with value and time stamp in ms. The time interval between 2 events depends on how often events occur (maxi-
mum once every scan time). Data logging is continuous, but if an alarm occurs, the log is saved and the values can be viewed on the
display. This feature is useful, for example when carrying out service following a trip. View the historic log contained in this parame-
ter via the serial communication port or via the display.
Danfoss A/S © 2022.12
N O T I C E
Parameter Descriptions
AU275636650261en-000101 / 130R0334 | 487
