VLT AutomationDrive FC 301/302
Programming Guide
Option
Name
[1616]
Torque [Nm]
[1617]
Speed [RPM]
[1618]
Motor thermal
[1620]
Motor angle
[1621]
Torque [%] high res.
[1622]
Torque [%]
[1624]
Calibrated stator resistance
[1625]
Torque [Nm] high
[1628]
Angle error
[1630]
DC link voltage
[1632]
Brake energy /s
[1633]
Brake energy average
[1634]
Heatsink temp.
[1635]
Inverter thermal
[1645]
Motor phase U current
[1646]
Motor phase V current
[1647]
Motor phase W current
[1648]
Speed ref. after ramp [RPM]
[1650]
External reference
[1651]
Pulse reference
[1652]
Feedback[Unit]
[1657]
Feedback [RPM]
[1660]
Digital input
[1662]
Analog input 53
[1664]
Analog input 54
[1665]
Analog output 42 [mA]
[1666]
Digital output [bin]
[1675]
Analog in X30/11
[1676]
Analog in X30/12
[1677]
Analog out X30/8 [mA]
[1687]
Bus readout alarm/warning
[1689]
Configurable alarm/warning word
480 | Danfoss A/S © 2022.12
Description
This option is only available with software version 48.XX.
Parameter Descriptions
AU275636650261en-000101 / 130R0334
