Option
[63] Comparator 3
[64] Comparator 4
[65] Comparator 5
[66] Comparator 6
[67] Comparator 7
[68] Comparator 8
[69] Comparator 9
[70] Logic rule 0
[71] Logic rule 1
[72] Logic rule 2
[73] Logic rule 3
[74] Logic rule 4
[75] Logic rule 5
[80] SL digital output A
[81] SL digital output B
[82] SL digital output C
[83] SL digital output D
[84] SL digital output E
[85] SL digital output F
Danfoss A/S © 2022.12
Function
See parameter group 13-1* Comparators. If comparator 3 is evaluated as true, the output goes high.
Otherwise, it is low.
See parameter group 13-1* Comparators. If comparator 4 is evaluated as true, the output goes high.
Otherwise, it is low.
See parameter group 13-1* Comparators. If comparator 5 is evaluated as true, the output goes high.
Otherwise, it is low.
See parameter group 13-1* Comparators. If comparator 6 is evaluated as true, the output goes high.
Otherwise, it is low.
See parameter group 13-1* Comparators. If comparator 7 is evaluated as true, the output goes high.
Otherwise, it is low.
See parameter group 13-1* Comparators. If comparator 8 is evaluated as true, the output goes high.
Otherwise, it is low.
See parameter group 13-1* Comparators. If comparator 9 is evaluated as true, the output goes high.
Otherwise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 0 is evaluated as true, the output goes high.
Otherwise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 1 is evaluated as true, the output goes high.
Otherwise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 2 is evaluated as true, the output goes high.
Otherwise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 3 is evaluated as true, the output goes high.
Otherwise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 4 is evaluated as true, the output goes high.
Otherwise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 5 is evaluated as true, the output goes high.
Otherwise, it is low.
See parameter 13-52 SL Controller Action. The output goes high whenever the smart logic action
[38] Set dig. out. A high is executed. The output goes low whenever the smart logic action [32] Set
dig. out. A low is executed.
See parameter 13-52 SL Controller Action. The output goes high whenever the smart logic action
[39] Set dig. out. B high is executed. The output goes low whenever the smart logic action [33] Set
dig. out. B low is executed.
See parameter 13-52 SL Controller Action. The output goes high whenever the smart logic action
[40] Set dig. out. C high is executed. The output goes low whenever the smart logic action [34] Set
dig. out. C low is executed.
See parameter 13-52 SL Controller Action. The output goes high whenever the smart logic action
[41] Set dig. out. D high is executed. The output goes low whenever the smart logic action [35] Set
dig. out. D low is executed.
See parameter 13-52 SL Controller Action. The output goes high whenever the smart logic action
[42] Set dig. out. E high is executed. The output goes low whenever the smart logic action [36] Set
dig. out. E low is executed.
See parameter 13-52 SL Controller Action. The output goes high whenever the smart logic action
[43] Set dig. out. F high is executed. The output goes low whenever the smart logic action [37] Set
dig. out. F low is executed.
