VLT AutomationDrive FC 301/302
Programming Guide
Option Name
[1636] Inv. Nom. Current
[1637] Inv. Max. Current
[1638] SL Controller State
[1639] Control Card Temp.
[1642] Service Log Counter
[1643] Timed Actions Status
[1644] Speed Error [RPM]
[1645] Motor Phase U Current
[1646] Motor Phase V Current
[1647] Motor Phase W Current
[1648] Speed. Ref. After Ramp [RPM]
[1650] External Reference
[1651] Pulse Reference
[1652] Feedback[Unit]
[1653] Digi Pot Reference
[1657] Feedback [RPM]
[1660] Digital Input
[1661] Terminal 53 Switch Setting
[1662] Analog Input 53
[1663] Terminal 54 Switch Setting
[1664] Analog Input 54
[1665] Analog Output 42 [mA]
[1666] Digital Output [bin]
[1667] Freq. Input #29 [Hz]
[1668] Freq. Input #33 [Hz]
[1669] Pulse Output #27 [Hz]
[1670] Pulse Output #29 [Hz]
[1671] Relay Output [bin]
[1672] Counter A
[1673] Counter B
[1674] Prec. Stop Counter
44 | Danfoss A/S © 2022.12
Description
Nominal current of the inverter.
Maximum current of the inverter.
State of the event executed by the control.
Temperature of the control card.
See parameter group 23-0* Timed Actions.
Sum of the external reference as a percentage, that is, the sum of analog/pulse/bus.
Frequency in Hz connected to the digital inputs (18, 19 or 32, 33).
Reference value from programmed digital inputs.
View the contribution of the digital potentiometer to the actual refernece feedback.
Signal states from the 6 digital terminals (18, 19, 27, 29, 32, and 33). There are 16 bits
in total, but only 6 of them are used. Input 18 corresponds to the far left of the used
bits. Signal log=0; Signal high=1.
Setting of input terminal 53. Current=0; Voltage=1.
Actual value at input 53 either as a reference or protection value.
Setting of input terminal 54. Current=0; Voltage=1.
Actual value at input 54 either as reference or protection value.
Actual value at output 42 in mA. Use parameter 6-50 Terminal 42 Output to select the
value to be shown.
Binary value of all digital outputs.
Actual value of the frequency applied at terminal 29 as an impulse input.
Actual value of the frequency applied at terminal 33 as an impulse input.
Actual value of impulses applied to terminal 27 in digital output mode.
Actual value of impulses applied to terminal 29 in digital output mode.
View the settings of all relays.
Application-dependent (for example, SLC control).
Application-dependent( for example, SLC control).
Shows the actual value of the counter.
Parameter Descriptions
