VLT AutomationDrive FC 301/302
Programming Guide
Table 4: Functional Groups of NLCP
1 Numerical display.
2 Menu keys and indicator lights - changing parameters and switching between display functions.
3 Navigation keys and indicator lights.
4 Operation keys and indicator lights.
Display line
Status messages showing icons and numeric value.
Indicator lights
• Green LED/On: indicates if control section is on.
• Yellow LED/Wrn: indicates a warning.
• Flashing red LED/Alarm: indicates an alarm.

4.2.1 LCP Keys

The control keys are divided into functions. The keys below the display and indicator lights are used for parameter setup, including
option of display indication during normal operation.
Table 5: LCP Keys and Description
LCP keys Description
[Status]
Indicates the status of the drive and/or the motor.
If an alarm occurs, the NLCP automatically switches to status mode. Several alarms can be shown.
Parameter copy is not possible with LCP 101 numerical local control panel.
Illustration 22: Status Mode
Illustration 23: Alarm
[Quick Used for programming the parameters in the Quick Menu and Main Menu, respectively. When the value flashes,
Menu]/ press [▵] or [▿] to change parameter values. Parameters with functional options show values such as [1], [2], and so
[Main on. For a description of the different options, see the individual parameter descriptions in
Menu]
Danfoss A/S © 2022.12
22.8
A 17
N O T I C E
r pm
S etup 1
S etup 1
How to Program
5 Parameter Descriptions.
