VLT AutomationDrive FC 301/302
Programming Guide
Option Name
[47] Bus ctrl, 0 if timeout
[50] On reference
[51] MCO controlled
[59] Remote, enable, no TW
[60] Comparator 0
[61] Comparator 1
[62] Comparator 2
[63] Comparator 3
[64] Comparator 4
[65] Comparator 5
[66] Comparator 6
[67] Comparator 7
[68] Comparator 8
[69] Comparator 9
[70] Logic rule 0
[71] Logic rule 1
[72] Logic rule 2
[73] Logic rule 3
[74] Logic rule 4
[75] Logic rule 5
[76] Logic rule 6
[77] Logic rule 7
212 | Danfoss A/S © 2022.12
Description
Controls output via bus. The state of the output is set in parameter 5-90 Digital & Relay Bus
Control. If a bus timeout occurs, the output state is set low (off).
See parameter group 13-1* Comparators. If comparator 0 in SLC is true, the output goes high.
Otherwise, it is low.
See parameter group 13-1* Comparators. If comparator 1 in SLC is true, the output goes high.
Otherwise, it is low.
See parameter group 13-1* Comparators. If comparator 2 in SLC is true, the output goes high.
Otherwise, it is low.
See parameter group 13-1* Comparators. If comparator 3 in SLC is true, the output goes high.
Otherwise, it is low.
See parameter group 13-1* Comparators. If comparator 4 in SLC is true, the output goes high.
Otherwise, it is low.
See parameter group 13-1* Comparators. If comparator 5 in SLC is true, the output goes high.
Otherwise, it is low.
See parameter group 13-1* Comparators. If comparator 6 in SLC is true, the output goes high.
Otherwise, it is low.
See parameter group 13-1* Comparators. If comparator 7 in SLC is true, the output goes high.
Otherwise, it is low.
See parameter group 13-1* Comparators. If comparator 8 in SLC is true, the output goes high.
Otherwise, it is low.
See parameter group 13-1* Comparators. If comparator 9 in SLC is true, the output goes high.
Otherwise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 0 in SLC is true, the output goes high. Oth-
erwise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 1 in SLC is true, the output goes high. Oth-
erwise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 2 in SLC is true, the output goes high. Oth-
erwise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 3 in SLC is true, the output goes high. Oth-
erwise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 4 in SLC is true, the output goes high. Oth-
erwise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 5 in SLC is true, the output goes high. Oth-
erwise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 6 in SLC is true, the output goes high. Oth-
erwise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 7 in SLC is true, the output goes high. Oth-
erwise, it is low.
Parameter Descriptions
