VLT AutomationDrive FC 301/302
Programming Guide
Option Name
[1788] Master home position
[3310] Sync factor master
[3311] Sync factor slave
[3401] PCD 1 write to MCO
[3402] PCD 2 write to MCO
[3403] PCD 3 write to MCO
[3404] PCD 4 write to MCO
[3405] PCD 5 write to MCO
[3406] PCD 6 write to MCO
[3407] PCD 7 write to MCO
[3408] PCD 8 write to MCO
[3409] PCD 9 write to MCO
[3410] PCD 10 write to MCO
[3644] Terminal X49/7 bus control
[3654] Terminal X49/9 bus control
[3664] Terminal X49/11 bus control
[4520] Type
Parameter 9-16 PCD Read Configuration
Table 545: Parameter 9-16 PCD Read Configuration
9-16 PCD Read Configuration
Default value: Size related
Conversion index: –
Select the parameters to be assigned to PCD 3–10 of the telegrams. The number of available PCDs depends on the telegram type.
Values in PCD 3–10 are written to the selected parameters as data. For standard PROFIBUS telegrams, see parameter 9-22 Telegram
Selection.
Option Name
[-] None
[15] Readout: actual setup
[1397] Alert alarm word
[1398] Alert warning word
[1399] Alert status word
[1472] Legacy alarm word
[1473] Legacy warning word
306 | Danfoss A/S © 2022.12
Parameter type: Option, Array 156
Data type: Uint16
Parameter Descriptions
Description
Setup: All setups
Change during operation: True
Description
