How to Programme
2 2
Illustration 2.7
Status screen III
This state displays the event and action of the Smart Logic
Control. For further information, see 3.12 Parameters 13-**
Smart Logic Control.
Illustration 2.8
2.2.5 Parameter Set-Up, General
Information
The frequency converter can be used for practically all
assignments, which is why the number of parameters is
quite large. The frequency converter offers a choice
between two programming modes - a Main Menu and a
Quick Menu mode.
The former provides access to all parameters. The latter
takes the user through a few parameters making it
possible to program the majority of water/wastewater
applications.
Regardless of the mode of programming, parameter can
be changes in both the Main Menu mode and in the Quick
Menu mode.

2.2.6 Quick Menu Key Functions

Pressing [Quick Menus]
The list indicates the different areas contained in the Quick
menu.
16
Status
207RPM 5.25A
1.1
6.9
Hz
Auto Remote Running
Status
778 RPM 0.86 A
State: 0 o 0 (o )
When: -
Do: -
Auto Remote Running
MG20O602 - VLT
®
VLT AQUA Drive Programming Guide
1 (1)
24.4 kW
1.3
1.2
Illustration 2.9
2
Select My Personal Menu to display the chosen personal
parameters. These parameters are selected in 0-25 My
Personal Menu. Up to 20 different parameters can be
added in this menu.
Select Quick Setup to go through a limited amount of
parameters to get the motor running almost optimally. The
default setting for the other parameters considers the
desired control functions and the configuration of signal
1 (1)
inputs/outputs (control terminals).
4.0 kW
The selection of parameter is effected by means of the
navigation keys. The parameters in Table 2.1 are accessible
in the Quick Set-up.
Parameter
0-01 Language
1-20 Motor Power [kW]
1-22 Motor Voltage
1-23 Motor Frequency
1-24 Motor Current
1-25 Motor Nominal Speed
3-41 Ramp 1 Ramp Up Time
3-42 Ramp 1 Ramp Down Time [sec]
1-29 Automatic Motor
Adaptation (AMA)
Table 2.1 Parameters in Quick Set-up
Select Changes made to get information about:
•
•
•
Select Loggings to get information about the display line
read-outs. The information is shown as graphs.
It is possible to store up to 120 samples in the memory for
later reference.
®
is a registered Danfoss trademark
40.0% 4.84 A
Quick Menus
Q1 My Personal Menu
Q2 Quick Setup
Q3 Function Setups
Q5 Changes Made
Unit
[kW]
[V]
[Hz]
[A]
[rpm]
[sec]
[1] Enable complete AMA
the last 10 changes. Use the [
between the last 10 changed parameters.
the changes made since default setting.
input assignments
1(1)
▲ ▼
] [ ] keys to scroll
