Option Name
[121] Remote ref active
[122] No alarm
[123] Start command ac-
tive
[124] Running reverse
[125] Drive in hand mode
[126] Drive in auto mode
[151] ATEX ETR cur. alarm
[152] ATEX ETR freq.
alarm
[153] ATEX ETR cur. warn-
ing
[154] ATEX ETR freq.
warning
[173] 10Wh counter pulse
[178] RS Flipflop 8
[179] RS Flipflop 9
[180] Clock fault
[181] Prev. Maintenance
[188] AHF Capacitor Con-
nect
[189] External Fan Control
[190] Safe Function active
[191] Safe Opt. Reset req.
[192] RS Flipflop 0
[193] RS Flipflop 1
[194] RS Flipflop 2
[195] RS Flipflop 3
[196] RS Flipflop 4
[197] RS Flipflop 5
[198] RS Flipflop 6
214 | Danfoss A/S © 2022.12
Description
Output is high when parameter 3-13 Reference Site = [1] Remote or [0] Linked to hand/auto while
the LCP.
Output is high when no alarm is present.
Output is high when the start command is high (that is via digital input, bus connection, [Hand
On], or [Auto On]), and a stop has been the last command.
Output is high when the drive is running counterclockwise (the logical product of the status bits
running AND reverse).
Output is high when the drive is in hand-on mode (as indicated by the LED light above [Hand
On]).
Output is high when the drive is in auto-on mode (as indicated by LED light on above [Auto
On]).
Selectable if parameter 1-90 Motor Thermal Protection is set to [20] ATEX ETR or [21] Advanced ETR.
If alarm 164, ATEX ETR cur.lim.alarm is active, the output is 1.
Selectable if parameter 1-90 Motor Thermal Protection is set to [20] ATEX ETR or [21] Advanced ETR.
If alarm 166, ATEX ETR freq.lim.alarm is active, the output is 1.
Selectable if parameter 1-90 Motor Thermal Protection is set to [20] ATEX ETR or [21] Advanced ETR.
If alarm 163, ATEX ETR cur.lim.warning is active, the output is 1.
Selectable if parameter 1-90 Motor Thermal Protection is set to [20] ATEX ETR or [21] Advanced ETR.
If warning 165, ATEX ETR freq.lim.warning is active, the output is 1.
See parameter group 13-1* Comparators.
See parameter group 13-1* Comparators.
The internal logics for the internal fan control is transferred to this output to make it possible to
control an external fan (relevant for hp duct cooling).
See parameter group 13-1* Comparators.
See parameter group 13-1* Comparators.
See parameter group 13-1* Comparators.
See parameter group 13-1* Comparators.
See parameter group 13-1* Comparators.
See parameter group 13-1* Comparators.
See parameter group 13-1* Comparators.
