VLT AutomationDrive FC 301/302
Programming Guide
Parameter 32-03 Absolute Resolution
Table 1114: Parameter 32-03 Absolute Resolution
32-03 Absolute Resolution
Default value: 8192
Conversion index: 0
The encoder resolution is used for calculating velocity in RPM. Set the resolution of the absolute encoder connected to terminal X55
in positions per revolution. Find the encoder resolution on the encoder nameplate.
Parameter 32-04 Absolute Encoder Baudrate X55
Table 1115: Parameter 32-04 Absolute Encoder Baudrate X55
32-04 Absolute Encoder Baudrate X55
Default Value: [4] 9600
Conversion Index: -
Select the baud rate of the attached encoder.
Option
[0]
[1]
[2]
[3]
[4]*
[5]
[6]
32-05 Absolute Encoder Data Length
Table 1116: 32-05 Absolute Encoder Data Length
32-05 Absolute Encoder Data Length
Default value: 25
Conversion index: 0
Specify the number of data bits for the connected absolute encoder, see encoder datasheet. This specification is required for VLT®
Motion Control Option MCO 305 and VLT® Motion Control Option MCO 302 to generate the correct number of clock bits.
Parameter 32-06 Absolute Encoder Clock Frequency
Table 1117: Parameter 32-06 Absolute Encoder Clock Frequency
32-06 Absolute Encoder Clock Frequency
Default value: 262
Conversion index: 3
Specifies the frequency of the absolute encoder clock signal generated by VLT® Motion Control Option MCO 305 and VLT® Motion
Control Option MCO 302. Set a frequency appropriate for the connected encoder.
Danfoss A/S © 2022.12
Parameter type: Range, 0 - 1073741823
Data type: Uint32
Parameter Type: Option
Data Type: Uint8
Name
600
1200
2400
4800
9600
19200
38400
Parameter type: Range, 8 - 37
Data type: Uint8
Parameter type: Range, 78.125 - 2000 kHz
Data type: Uint32
Setup: All setups
Change during operation: True
Setup: 2 setups
Change during operation: True
Description
Setup: 2 setups
Change during operation: True
Setup: 2 setups
Change during operation: True
AU275636650261en-000101 / 130R0334 | 589
Parameter Descriptions
