VLT AutomationDrive FC 301/302
Programming Guide
The following parameters are only available in FC 302:
-
Parameter 1-02 Flux Motor Feedback Source
-
Parameter 1-07 Motor Angle Offset Adjust
Parameter 1-00 Configuration Mode
Table 58: Parameter 1-00 Configuration Mode
1-00 Configuration Mode
Default value: Size related
Conversion index: –
Select the application control principle to be used when a remote reference (that is via analog input or fieldbus) is active. A remote
reference can only be active when parameter 3-13 Reference Site is set to [0] Linked to Hand/Auto or [1] Remote.
Op- Name
tion
[0] Speed open
loop
[1] Speed closed
loop
[2] Torque
[3] Process
[4] Torque open
loop
[5] Wobble
[6] Surface winder
[7] Extended PID
speed OL
[8] Extended PID
speed CL
[9] Positioning
Danfoss A/S © 2022.12
N O T I C E
Parameter type: Option
Data type: Uint8
Description
Enables speed control (without feedback signal from motor) with automatic slip compensation for
almost constant speed at varying loads. Compensations are active, but can be disabled in parameter
group 1-** Load and Motor. Set the speed control parameters in parameter group 7-0* Speed PID Ctrl.
Enables speed closed-loop control with feedback. Obtain full holding torque at 0 RPM. For increased
speed accuracy, provide a feedback signal and set the speed PID control. Set the speed control pa-
rameters in parameter group 7-0* Speed PID Ctrl.
This option is only available in FC 302.
Enables torque closed-loop control with feedback. Only possible when parameter 1-01 Motor Control
Principle is set to [3] Flux w/motor feedb.
Enables the use of process control in the drive. Set the process control parameters in parameter
groups 7-2* Process Ctrl. Feedb. and 7-3* Process PID Ctrl.
Enables the use of torque open-loop mode (parameter 1-01 Motor Control Principle). Set the torque
PID parameters in parameter group 7-1* Torque PI Control.
Enables the wobble functionality in parameter 30-00 Wobble Mode to parameter 30-19 Wobble Delta
Freq. Scaled.
Enables the surface winder control-specific parameters in parameter groups 7-2* Process Ctrl. Feedb.
and 7-3* Process PID Ctrl.
Specific parameters in parameter groups 7-2* Process Ctrl. Feedb. to 7-5* Ext. Process PID Ctrl.
Specific parameters in parameter groups 7-2* Process Ctrl. Feedb. to 7-5* Ext. Process PID Ctrl.
This option is only available with software version 48.XX.
Activates positioning mode.
Setup: All setups
Change during operation: True
N O T I C E
N O T I C E
AU275636650261en-000101 / 130R0334 | 63
