VLT AutomationDrive FC 301/302
Programming Guide
Option
[0]*
[1]
Parameter 17-61 Feedback Signal Monitoring
Table 937: Parameter 17-61 Feedback Signal Monitoring
17-61 Feedback Signal Monitoring
Default value: [1] Warning
Conversion index: -
Select which action the drive should take if a faulty encoder signal is detected. The encoder function in parameter 17-61 Feedback
Signal Monitoring is an electrical check of the hardware circuit in the encoder system.
Option
[0]
[1]*
[2]
[3]
[4]
[5]
[6]
[7]
[8]
[9]
[10]
[11]
[12]
[13]
Parameter 17-67 Raw Inc. Quad Counter
Table 938: Parameter 17-67 Raw Inc. Quad Counter
17-67 Raw Inc. Quad Counter
Default value: 0
Conversion index: 0
This parameter is only available with software version 48.9X.
Shows the raw incremental counter value in quad counts (4 times pulse count) of an encoder connected to VLT® Encoder Input MCB
102. It can be an incremental encoder or the incremental part of a dual-channel absolute encoder. MCB 102 must be selected as
524 | Danfoss A/S © 2022.12
Name
Clockwise
Counter clockwise
Parameter type: Option
Data type: Uint8
Name
Disabled
Warning
Trip
Jog
Freeze output
Max speed
Switch to open loop
Select setup 1
Select setup 2
Select setup 3
Select setup 4
Stop & trip
Trip/warning
Trip/catch
Parameter type: Range, 0 - 65535
Data type: Uint16
N O T I C E
Parameter Descriptions
Description
Setup: All setups
Change during operation: False
Description
Setup: All setups
Change during operation: False
AU275636650261en-000101 / 130R0334
