Etr; Atex Etr - Danfoss VLT AutomationDrive FC 301 Programming Manual

VLT AutomationDrive FC 301/302
Programming Guide
4500
4000
3500
3000
2500
2000
1500
1000
500
0
-25 0 25
KTY Type 1
Illustration 42: KTY Type Selection
KTY Sensor 1: 1 kΩ at 100 °C (212 °F) (for example Philips KTY 84-1)
KTY Sensor 2: 1 kΩ at 25 °C (77 °F) (for example Philips KTY 83-1)
KTY Sensor 3: 2 kΩ at 25 °C (77 °F) (for example Infineon KTY-10)
If the temperature of the motor is utilized through a thermistor or KTY sensor, the PELV is not complied with if there are short
circuits between motor windings and the sensor. Put extra isolation on the sensor to comply with PELV.

5.2.10.3 ETR

The calculations estimate the need for a lower load at lower speed due to less cooling from the fan incorporated in the motor.
t [s]
2000
1000
600
500
400
300
200
100
60
50
40
30
20
10
1.0 1.2 1.4
Illustration 43: ETR Profile

5.2.10.4 ATEX ETR

The VLT® PTC Thermistor Card MCB 112 offers ATEX-approved monitoring of motor temperature. Alternatively, an external ATEX-
approved PTC protection device can be used.
Danfoss A/S © 2022.12
50 75 100 125 150
Temperature [°C]
KTY Type 2 KTY Type 3
