VLT AutomationDrive FC 301/302
Programming Guide
Option
[2]
[3]
[4]
Example
Use multi set-up to shift from setup 1 to setup 2 while the motor is running. Program in setup 1 first, then ensure that setup 1 and
setup 2 are synchronized (or linked). Synchronization can be performed in 2 ways:
• Select the following options:
- [2] Set-up 2 in parameter 0-11 Edit Set-up
- Set parameter 0-12 This Set-up Linked to to [1] Set-up 1.
0 RPM
Set-up Handling
0-12 This Set-up Linked to
[1] Setup 1
Illustration 26: Setup 1
•
While still in setup 1, copy setup 1 to setup 2. Then set parameter 0-12 This Set-up Linked to to [2] Set-up 2.
0 RPM
Set-up Handling
0-12 This Set-up Linked to
[2] Setup 2
Illustration 27: Setup 2
Parameter 0-13 Readout: Linked Set-ups
Table 14: Parameter 0-13 Readout: Linked Set-ups
0-13 Readout: Linked Set-ups
Default value: 0
Conversion index: 0
View a list of all the setups linked by parameter 0-12 This Set-up Linked to. The parameter has 1 index for each parameter setup. The
value for each index shows which setups are linked to that parameter setup.
40 | Danfoss A/S © 2022.12
Name
Set-up 2
Set-up 3
Set-up 4
0.00A
0.00A 1(1)
0-1*
Parameter type: Range, 0 – 255, Array [5]
Data type: Uint16
Description
1(1)
0-1*
Setup: All setups
Change during operation: False
Parameter Descriptions
