VLT AutomationDrive FC 301/302
Programming Guide
Option Name
[0] False
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current limit
[7] Out of current range
[8] Below I
low
[9] Above I
high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
374 | Danfoss A/S © 2022.12
Description
Select the boolean (true or false) input to activate smart logic control. Enters the fixed value
False.
Enters the fixed value True.
The motor runs.
The motor runs within the programmed current and speed ranges set in parameter 4-50 Warn-
ing Current Low to parameter 4-53 Warning Speed High.
The motor runs on reference.
The torque limit set in parameter 4-16 Torque Limit Motor Mode or parameter 4-17 Torque Limit
Generator Mode is exceeded.
The motor current limit set in parameter 4-18 Current Limit is exceeded.
The motor current is outside the range set in parameter 4-18 Current Limit.
The motor current is lower than set in parameter 4-50 Warning Current Low.
The motor current is higher than set in parameter 4-51 Warning Current High.
The speed is outside the range set in parameter 4-52 Warning Speed Low and parameter 4-53
Warning Speed High.
The output speed is lower than the setting in parameter 4-52 Warning Speed Low.
The output speed is higher than the setting in parameter 4-53 Warning Speed High.
The feedback is outside the range set in parameter 4-56 Warning Feedback Low and parameter
4-57 Warning Feedback High.
The feedback is below the limit set in parameter 4-56 Warning Feedback Low.
The feedback is above the limit set in parameter 4-57 Warning Feedback High.
The thermal warning turns on when the temperature exceeds the limit in the motor, the drive,
the brake resistor, or the thermistor.
The mains voltage is outside the specified voltage range.
The output is high when the drive is running counterclockwise (the logical product of the status
bits running AND reverse).
A warning is active.
A (trip) alarm is active.
A (trip lock) alarm is active.
Use the result of comparator 0.
Use the result of comparator 1.
Use the result of comparator 2.
Use the result of comparator 3.
Use the result of logic rule 0.
Use the result of logic rule 1.
Parameter Descriptions
