Danfoss VLT AutomationDrive FC 301 Programming Manual page 592

VLT AutomationDrive FC 301/302
Programming Guide
Enter the node ID for the feedback CAN encoder.
Parameter 32-15 Enc.2 CAN Guard
Table 1126: Parameter 32-15 Enc.2 CAN Guard
32-15 Enc.2 CAN Guard
Default value: [0] Off
Conversion index: -
Select if the feedback CAN encoder guardians should be off or on.
Option
[0]*
[1]
5.25.2 32-3* Encoder 1
Parameter 32-30 Incremental Signal Type
Table 1127: Parameter 32-30 Incremental Signal Type
32-30 Incremental Signal Type
Default value: [1] RS422 (5V TTL)
Conversion index: -
Option
[0]
[1]*
[3]
Parameter 32-31 Incremental Resolution
Table 1128: Parameter 32-31 Incremental Resolution
32-31 Incremental Resolution
Default value: 1024
Conversion index: 0
Set the resolution of the incremental encoder connected to terminal X56. The maximum frequency must not exceed 410 kHz.
Parameter 32-32 Absolute Protocol
Table 1129: Parameter 32-32 Absolute Protocol
32-32 Absolute Protocol
Default value: [0] None
Conversion index: -
Option
[0]*
[1]
[2]
592 | Danfoss A/S © 2022.12
Parameter type: Option
Data type: Uint8
Name
Off
On
Parameter type: Option
Data type: Uint8
Name
None
RS422 (5V TTL)
CAN encoder
Parameter type: Range, 1 - 1073741823
Data type: Uint32
Parameter type: Option
Data type: Uint8
Name
None
HIPERFACE
EnDat
Setup: 2 setups
Change during operation: True
Description
Setup: 2 setups
Change during operation: True
Description
Setup: 2 setups
Change during operation: True
Setup: 2 setups
Change during operation: True
Description
AU275636650261en-000101 / 130R0334
Parameter Descriptions
