Danfoss VLT AutomationDrive FC 301 Programming Manual page 328

VLT AutomationDrive FC 301/302
Programming Guide
Option
[20]
[21]
[22]
Parameter 10-02 MAC ID
Table 581: Parameter 10-02 MAC ID
10-02 MAC ID
Default value: Size related
Conversion index: 0
Select the station address. Every station connected to the same network must have an unambiguous address.
Parameter 10-05 Readout Transmit Error Counter
Table 582: Parameter 10-05 Readout Transmit Error Counter
10-05 Readout Transmit Error Counter
Default value: 0
Conversion index: 0
View the number of CAN control transmission errors since the last power-up.
Parameter 10-06 Readout Receive Error Counter
Table 583: Parameter 10-06 Readout Receive Error Counter
10-06 Readout Receive Error Counter
Default value: 0
Conversion index: 0
View the number of CAN control receipt errors since the last power-up.
Parameter 10-07 Readout Bus Off Counter
Table 584: Parameter 10-07 Readout Bus Off Counter
10-07 Readout Bus Off Counter
Default value: 0
Conversion index: 0
5.11.2 10-1* DeviceNet
Parameter 10-10 Process Data Type Selection
Table 585: Parameter 10-10 Process Data Type Selection
10-10 Process Data Type Selection
Default value: Size related
Conversion index: –
Select the instance (telegram) for data transmission. The instances available depend on the setting of parameter 8-10 Control Word
Profile. When parameter 8-10 Control Word Profile is set to [0] FC Profile, options [0] INSTANCE 100/150 and [1] INSTANCE 101/151 in this
parameter are available. When parameter 8-10 Control Word Profile is set to [5] ODVA, options [2] INSTANCE 20/70 and [3] INSTANCE
328 | Danfoss A/S © 2022.12
Name
125 Kbps
250 Kbps
500 Kbps
Parameter type: Range, [N/A]
Data type: Uint8
Parameter type: Range, 0 - 255
Data type: Uint8
Parameter type: Range, 0 - 255
Data type: Uint8
Parameter type: Range, 0 - 255
Data type: Uint8
Parameter type: Option
Data type: Uint8
Parameter Descriptions
Description
Setup: 2 setups
Change during operation: True
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
AU275636650261en-000101 / 130R0334
