Danfoss VLT AutomationDrive FC 301 Programming Manual page 213

VLT AutomationDrive FC 301/302
Programming Guide
Option Name
[78] Logic rule 8
[79] Logic rule 9
[80] SL digital output A
[81] SL digital output B
[82] SL digital output C
[83] SL digital output D
[84] SL digital output E
[85] SL digital output F
[90] kWh counter pulse
[96] Reverse after ramp
[98] Virtual master dir.
[120] Local ref active
Table 361: Local Reference Active
Reference site set in parameter 3-1 3 Reference Site
Reference site: Local parameter 3-13 Reference Site [2] Local
Reference site: Remote parameter 3-13 Reference Site [1] Remote
Reference site: Linked to Hand/ Auto
Hand
Hand⇒off
Auto⇒off
Auto
Danfoss A/S © 2022.12
Description
See parameter group 13-4* Logic Rules. If logic rule 8 in SLC is true, the output goes high. Oth-
erwise, it is low.
See parameter group 13-4* Logic Rules. If logic rule 9 in SLC is true, the output goes high. Oth-
erwise, it is low.
See parameter 13-52 SL Controller Action. Output A is low on smart logic action [32] Set digital
out A low. Output A is high on smart logic action [38].
See parameter 13-52 SL Controller Action. Output B is low on smart logic action [33] Set digital
out B low. Output B is high on smart logic action [39].
See parameter 13-52 SL Controller Action. Output C is low on smart logic action [34] Set digital
out C low. Output C is high on smart logic action [40].
See parameter 13-52 SL Controller 1 Action. Output D is low on smart logic action [35] Set digi-
tal out D low. Output D is high on smart logic action [41].
See parameter 13-52 SL Controller Action. Output E is low on smart logic action [36] Set digital
out E low. Output E is high on smart logic action [42].
See parameter 13-52 SL Controller Action. Output F is low on smart logic action [37] Set digital
out F low. Output F is high on smart logic action [43].
This option is only available with software version 48.XX.
See the description in parameter group 5-3* Digital Outputs.
This option is only available with software version 48.XX.
See the description in parameter group 5-3* Digital Outputs.
Output is high when parameter 3-13 Reference Site = [2] Local or when parameter 3-13 Refer-
ence Site = [0] Linked to hand auto at the same time as the LCP is in hand-on mode.
N O T I C E
N O T I C E
Local reference active [120]
1
0
1
1
0
0
AU275636650261en-000101 / 130R0334 | 213
Parameter Descriptions
Remote reference active [121]
0
1
0
0
0
1
