VLT AutomationDrive FC 301/302
Programming Guide
CT characteristics
Commanded position
Control command
D
DSP
Digital inputs
Digital outputs
E
ETR
F
FC standard bus
f
M
f
M,N
f
MAX
f
MIN
f
jog
H
Hiperface
®
I
I
M
I
M,N
IMC
I
VLT,MAX
I
VLT,N
Initializing
718 | Danfoss A/S © 2022.12
Constant-torque characteristics used for all applications such as conveyor
belts, displacement pumps, and cranes.
The actual position reference calculated by the profile generator. The drive
uses the commanded position as setpoint for position PI.
Start and stop the connected motor with LCP and digital inputs.
Functions are divided into 2 groups.
Functions in group 1 have higher priority than functions in group 2.
Table 1: Function Groups
Group 1
Reset, coast stop, reset and coast stop,
quick stop, DC brake, stop, the LCP
[OFF] key.
Digital signal processor.
The digital inputs can be used for controlling various functions of the drive.
The drive features 2 solid-state outputs that can supply a 24 V DC (maxi-
mum 40 mA) signal.
Electronic thermal relay is a thermal load calculation based on present load
and time. Its purpose is to estimate the motor temperature.
Includes RS485 bus with FC protocol or MC protocol. See parameter 8-30
Protocol.
Motor frequency.
Rated motor frequency (nameplate data).
Maximum motor frequency.
Minimum motor frequency.
Motor frequency when the jog function is activated (via digital terminals).
Hiperface is a registered trademark by Stegmann.
®
Motor current (actual).
Rated motor current (nameplate data).
Integrated Motion Controller (IMC) is a functionality that enables an AC
drive to perform high-precision positioning and synchronization operations
without the need for additional modules or hardware.
Maximum output current.
Rated output current supplied by the drive.
If initializing is carried out in parameter 14-22 Operation Mode, the drive re-
turns to the default setting.
Glossary
Group 2
Start, pulse start, reversing, start
reversing, jog, freeze output.
