Option
[6] Running/no warn-
ing
[7] Run inrange/no
warn
[8] Run on ref/no warn
[9] Alarm
[10] Alarm or warning
[11] At torque limit
[12] Out of current
range
[13] Below current, low
[14] Above current, high
[15] Out of speed range
[16] Below speed, low
[17] Above speed, high
[18] Out of feedb. range
[19] Below feedback,
low
[20] Above feedback,
high
[21] Thermal warning
[22] Ready, no thermal
W
[23] Remote, ready, no
TW
[24] Ready, voltage OK
[25] Reverse
[26] Bus OK
[27] Torque limit & stop
[28] Brake, no brake war
[29] Brake ready, no
fault
Danfoss A/S © 2022.12
Function
The output speed is higher than the speed set in parameter 1-81 Min Speed for Function at Stop
[RPM]. The motor runs and there are no warnings.
The motor runs within the programmed current and speed ranges set in parameter 4-50 Warning
Current Low to parameter 4-53 Warning Speed High. There are no warnings.
The motor runs at reference speed. There are no warnings.
An alarm activates the output. There are no warnings.
An alarm or warning activates the output.
The torque limit set in parameter 4-16 Torque Limit Motor Mode or parameter 4-17 Torque Limit Gen-
erator Mode has been exceeded.
The motor current is outside the range set in parameter 4-18 Current Limit.
The motor current is lower than set in parameter 4-50 Warning Curent Low.
The motor current is higher than set in parameter 4-51 Warning Current High.
The output frequency is outside the frequency range set in parameter 4-52 Warning Speed Low and
parameter 4-53 Warning Speed High.
Output speed is lower than the setting in parameter 4-52 Warning Speed Low.
The output speed is higher than the setting in parameter 4-53 Warning Speed High.
Feedback is below the limit set in parameter 4-56 Warning Feedback Low and parameter 4-57 Warn-
ing Feedback High.
Feedback is below the limit set in parameter 4-56 Warning Feedback Low.
Feedback is above the limit set in parameter 4-57 Warning Feedback High.
The thermal warning turns on when the temperature exceeds the limit in the motor, the drive, the
brake resistor, or the thermistor.
The drive is ready for operation, and there is no overtemperature warning.
The drive is ready for operation and is in auto-on mode. There is no overtemperature warning.
The drive is ready for operation and the mains voltage is within the specified voltage range.
The motor runs (or is ready to run) clockwise when logic = 0 and runs counterclockwise when logic
= 1. The output changes when the reversing signal is applied.
Active communication (no timeout) via the serial communication port.
Used for coast stop and in torque limit conditions. If the drive has received a stop signal and is at
the torque limit, the signal is logic 0.
Brake is active, and there are no warnings.
Brake is ready for operation and there are no faults.
