VLT AutomationDrive FC 301/302
Programming Guide
Option
[0]
[1]
[2]
[3]*
5.9.7 8-8* FC Port Diagnostics
These parameters are used for monitoring the bus communication via the drive RS485 port terminals 68–69.
Parameter 8-80 Bus Message Count
Table 536: Parameter 8-80 Bus Message Count
8-80 Bus Message Count
Default value: 0
Conversion index: 0
This parameter shows the number of valid telegrams detected on the bus.
Parameter 8-81 Bus Error Count
Table 537: Parameter 8-81 Bus Error Count
8-81 Bus Error Count
Default value: 0
Conversion index: 0
This parameter shows the number of telegrams with faults (for example, CRC fault) detected on the bus.
Parameter 8-82 Slave Messages Rcvd
Table 538: Parameter 8-82 Slave Messages Rcvd
8-82 Slave Messages Rcvd
Default value: 0
Conversion index: 0
This parameter shows the number of valid telegrams addressed to the slave sent by the drive.
Parameter 8-83 Slave Error Count
Table 539: Parameter 8-83 Slave Error Count
8-83 Slave Error Count
Default value: 0
Conversion index: 0
This parameter shows the number of error telegrams which are not executed by the drive.
302 | Danfoss A/S © 2022.12
Name
Digital input
Bus
Logic AND
Logic OR
Parameter type: Range, 0 - 0
Data type: Uint32
Parameter type: Range, 0 - 0, Array [6]
Data type: Uint32
Parameter type: Range, 0 - 0
Data type: Uint32
Parameter type: Range, 0 - 0
Data type: Uint32
Parameter Descriptions
Description
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
AU275636650261en-000101 / 130R0334
