VLT AutomationDrive FC 301/302
Programming Guide
5.25.1 32-0* Encoder 2
Parameter 32-00 Incremental Signal Type
Table 1111: Parameter 32-00 Incremental Signal Type
32-00 Incremental Signal Type
Default value: [1] RS422 (5V TTL)
Conversion index: -
Option
[0]
[1]*
[2]
[3]
Parameter 32-01 Incremental Resolution
Table 1112: Parameter 32-01 Incremental Resolution
32-01 Incremental Resolution
Default value: 1024
Conversion index: 0
Set the resolution of the incremental encoder connected to terminal X55. The maximum frequency must not exceed 410 kHz.
Parameter 32-02 Absolute Protocol
Table 1113: Parameter 32-02 Absolute Protocol
32-02 Absolute Protocol
Default Value: [0] None
Conversion Index: -
Option
[0]*
[1]
[2]
[4]
[5]
[6]
[7]
588 | Danfoss A/S © 2022.12
Parameter type: Option
Data type: Uint8
Name
None
RS422 (5V TTL)
Sinusoidal 1Vpp
CAN encoder
Parameter type: Range, 1 - 1073741823
Data type: Uint32
Parameter Type: Option
Data Type: Uint8
Name
None
HIPERFACE
EnDat
SSI
SSI with filter
BiSS-C
BiSS-B
Parameter Descriptions
Setup: 2 setups
Change during operation: True
Description
Setup: All setups
Change during operation: True
Setup: 2 setups
Change during operation: True
Description
AU275636650261en-000101 / 130R0334
