Danfoss VLT AutomationDrive FC 301 Programming Manual page 442

VLT AutomationDrive FC 301/302
Programming Guide
Option Name
[238] RS flipflop 8
[239] RS flipflop 9
[240] SL digital output A
[241] SL digital output B
[242] SL digital output C
[243] SL digital output D
[244] SL digital output E
[245] SL digital output F
Parameter 13-58 SL Controller 4 Action
Table 693: Parameter 13-58 SL Controller 4 Action
13-58 SL Controller 4 Action
Default value: Size related
Conversion index: -
Select the action corresponding to the SLC event. Actions are executed when the corresponding event (defined in parameter 13-57
SL Controller 4 Event) is evaluated as true.
Option Name
[0] DISABLED
[1] No action
[2] Select set-up 1
[3] Select set-up 2
[4] Select set-up 3
[5] Select set-up 4
[10] Select preset ref 0
[11] Select preset ref 1
[12] Select preset ref 2
[13] Select preset ref 3
[14] Select preset ref 4
442 | Danfoss A/S © 2022.12
Description
Parameter type: Option, Array [20]
Data type: Uint8
Description
Changes the active setup (parameter 0-10 Active Set-up) to 1. If the setup is changed, it merges
with other setup commands coming from either the digital inputs or via a fieldbus.
Changes the active setup (parameter 0-10 Active Set-up) to 2. If the setup is changed, it merges
with other setup commands coming from either the digital inputs or via a fieldbus.
Changes the active setup (parameter 0-10 Active Set-up) to 3. If the setup is changed, it merges
with other setup commands coming from either the digital inputs or via a fieldbus.
Changes the active setup (parameter 0-10 Active Set-up) to 4. If the setup is changed, it merges
with other setup commands coming from either the digital inputs or via a fieldbus.
Selects preset reference 0. If the active preset reference is changed, it merges with other preset
reference commands coming from either the digital inputs or via a fieldbus.
Selects preset reference 1. If the active preset reference is changed, it merges with other preset
reference commands coming from either the digital inputs or via a fieldbus.
Selects preset reference 2. If the active preset reference is changed, it merges with other preset
reference commands coming from either the digital inputs or via a fieldbus.
Selects preset reference 3. If the active preset reference is changed, it merges with other preset
reference commands coming from either the digital inputs or via a fieldbus.
Selects preset reference 4. If the active preset reference is changed, it merges with other preset
reference commands coming from either the digital inputs or via a fieldbus.
Parameter Descriptions
Setup: 2 setups
Change during operation: True
AU275636650261en-000101 / 130R0334
