VLT AutomationDrive FC 301/302
Programming Guide
Number Description
211 Position limit
212 Homing not done
213 Homing timeout
214 No sensor input
215 Start fwd/rev
216 Touch timeout
220 Configuration File Version not sup-
ported
246 Power card supply
250 New spare part
251 New type code
280 Emcy m service warning
281 Emcy OPR unexpected
430 PWM disabled
Cannot be auto reset via parameter 14-20 Reset Mode.
1
(X) Dependent on parameter.
A trip is the action following an alarm. The trip coasts the motor and is reset by pressing [Reset] or by a digital input (parameter
group 5-1* Digital Inputs). The original event that caused an alarm cannot damage the drive or cause dangerous conditions.
A trip lock is an action when an alarm occurs, which could damage the drive or connected parts. A trip lock situation can only be
reset by cycling power.
7.1.3 Indicator Light
Table 1435: Indicator Light
Warning
Alarm
Trip locked
7.1.4 Alarm Word, Warning Word, and Extended Status Word
Table 1436: Description of Alarm Word
Bit Hex Dec
Alarm Word Extended Status Word
0 00000001 1
1 00000002 2
Danfoss A/S © 2022.12
Warning Alarm/trip
X X
– X
– X
– X
X X
– X
X –
– –
– –
– X
X –
X –
– X
Yellow
Flashing red
Yellow and red
Alarm word
Parameter 16-90 Alarm Word
Brake check (A28)
Pwr.card temp (A69)
Alarm/trip Parameter reference
lock
–
Parameter 3-06 Minimum Position, pa-
rameter 3-07 Maximum Position, parame-
ter 4-73 Position Limit Function
–
Parameter 17-80 Homing Function
–
Parameter 17-85 Homing Timeout
– –
– Parameter 4-74 Start Fwd/Rev Function
–
Parameter 4-75 Touch Timeout
– –
X –
X –
X –
– –
– –
– –
Alarm word 2
Parameter 16-91 Alarm Word 2
Servicetrip, read/ write
Servicetrip, (reserved)
AU275636650261en-000101 / 130R0334 | 695
Troubleshooting
Alarm word 3
Parameter 16-97 Alarm
Word 3
Temp. input error
Memory module fault
