VLT AutomationDrive FC 301/302
Programming Guide
This parameter cannot be adjusted while the motor is running.
Option Name
[0]* Input
[1] Output
Parameter 5-02 Terminal 29 Mode
Table 325: Parameter 5-02 Terminal 29 Mode
5-02 Terminal 29 Mode
Default value: [0] Input
Conversion index: –
Option Name
[0]* Input
[1] Output
5.6.2 5-1* Digital Inputs
The following parameter is only available in FC 302:
-
Parameter 5-13 Terminal 29 Digital Input
The digital inputs are used for selecting various functions in the drive. Refer to
digital inputs.
Functions in function group 1 have higher priority than functions in function group 2.
Table 326: Function Groups
Group Functions
1 Reset, coast stop, reset, and coast stop, quick stop, DC brake, stop, and the [Off] key.
2 Start, latched start, reversing, start reversing, jog, and freeze output.
Table 327: Digital Input Functions and Terminals
Digital input function
No operation
Reset
Coast inverse
Coast and reset inverse
Quick stop inverse
DC brake inverse
Stop inverse
176 | Danfoss A/S © 2022.12
N O T I C E
Description
Defines terminal 27 as a digital input.
Defines terminal 27 as a digital output.
Parameter type: Option
Data type: Uint8
Description
Defines terminal 29 as a digital input.
Defines terminal 29 as a digital output.
N O T I C E
Select
[0]
[1]
[2]
[3]
[4]
[5]
[6]
Parameter Descriptions
Setup: All setups
Change during operation: True
Table 327 for functions which can be assigned to
Terminal
All, terminal 32, 33
All
All, terminal 27
All
All
All
All
