VLT AutomationDrive FC 301/302
Programming Guide
For example, consider the following use case: If there is an active signal on digital input 32, the drive shows the message Valve 5
open and ramps down to a stop. To achieve this configuration, make the following settings:
•
Parameter 13-90 Alert Trigger = [37] Digital input DI32.
•
Parameter 13-91 Alert Action = [5] Stop & warning.
•
Parameter 13-92 Alert Text = Valve 5 open.
Actions reflected in parameter 16-03 Status Word and alert parameters
When an action containing trip is selected and triggered, the drive trips, bit 3 in the basic status word is set, and the corresponding
hex value is shown in parameter 13-97 Alert Alarm Word.
The alarm for User Alert is logged as alarm value = 124 in parameter 15-30 Fault Log: Error Code, index [0]–[9].
When an action containing warning info is selected and triggered, bit 7 in the basic status word is set, and the corresponding hex
value is shown in parameter 13-98 Alert Warning Word.
Other actions selected are not indicated in the basic status word, but the corresponding hex value is shown in parameter 13-99 Alert
Status Word.
Example of setting up digital inputs as triggers, actions, and readouts
Refer to the following table to understand the 3 examples in this section.
Table 694: Example of Setting up Triggers, Actions, and Readouts
ID Name
1390.0 Alert Trigger
1390.1 Alert Trigger
1390.2 Alert Trigger
1390.3 Alert Trigger
1390.4 Alert Trigger
1390.5 Alert Trigger
1390.6 Alert Trigger
1390.7 Alert Trigger
1390.8 Alert Trigger
1390.9 Alert Trigger
1391.0 Alert Action
1391.1 Alert Action
1391.2 Alert Action
1391.3 Alert Action
1391.4 Alert Action
1391.5 Alert Action
1391.6 Alert Action
1391.7 Alert Action
1391.8 Alert Action
1391.9 Alert Action
1392.0 Alert Text
1392.1 Alert Text
446 | Danfoss A/S © 2022.12
Setup 1
[34] Digital input DI19
[37] Digital input DI32
[0] False
[0] False
[0] False
[0] False
[0] False
[0] False
[38] Digital input DI33
[0] False
[0] Info
[1] Warning
[0] Info
[0] Info
[0] Info
[0] Info
[0] Info
[0] Info
[12] Trip
[0] Info
Dig In 19
Dig In 32
Parameter Descriptions
